Candlestick Patterns Strategy
Author: ChaoZhang, Date: 2024-01-18 15:14:13Tags:
Overview
This strategy determines buy and sell signals by identifying various price pattern formations on the candlestick chart. The strategy incorporates technical analysis methods such as Chanlun and Dow Theories, utilizing more than a dozen common graphical patterns to capture inflection points in the market.
Strategy Principle
The core of this strategy lies in recognizing different candlestick patterns, including engulfing lines, harami lines, piercing lines, morning stars etc. When a bullish pattern is identified, a buy signal is generated; when a bearish pattern is detected, a sell signal is triggered.
For example, when the Three White Soldiers pattern is recognized, it means that the last three candlesticks are all long green candles, and the closing price of each candle exceeds its opening price, indicating the strong buying is pushing up the price, so a buy signal is generated.
Each pattern has a specific algorithm to identify. The strategy scans through the historical candlesticks, judging if each bar meets the formulation algorithm of a certain pattern, and once it does, plot a graphical marker on that bar marking out that signal.
Advantages
- Combining judgments of various patterns improves winning rate
- Automatically pattern recognition without manual interference
- Visualized markers gives intuitiveness
- Controlling risks by integrating stop loss and take profit
Risks and Optimization
- Probability of failure still exists for patterns identification
- Fine tune the stop loss ratio properly to lower per trade loss
- Adding trend judgment to avoid reverse patterns
- Optimize session setting to eliminate overnight risks
Optimization Suggestions
- Include more auxiliary pattern judgments
- Add trend indicator filters for entry signals
- Optimize ratios of stop loss and take profit
- Try machine learning methods to recognize patterns
- Add position sizing control
Summary
This strategy determines future market moves by analyzing graphical patterns formed on the candlesticks bars using technical tools. The strategy is practical to use, but traders still need to take account of the general market environment, avoiding missing major trends because of local shapes. By further optimizations, it is promising to enhance the stability and profitability of the strategy.
/*backtest
start: 2024-01-10 00:00:00
end: 2024-01-17 00:00:00
period: 2h
basePeriod: 15m
exchanges: [{"eid":"Futures_Binance","currency":"BTC_USDT"}]
*/
//@version=2
strategy("Candle Patterns Strategy", shorttitle="CPS", overlay=true)
//--- Patterns Input ---
OnEngulfing = input(defval=true, title="Engulfing", type=bool)
OnHarami = input(defval=true, title="Harami", type=bool)
OnPiercingLine = input(defval=true, title="Piercing Line / Dark Cloud Cover", type=bool)
OnMorningStar = input(defval=true, title="Morning Star / Evening Star ", type=bool)
OnBeltHold = input(defval=true, title="Belt Hold", type=bool)
OnThreeWhiteSoldiers = input(defval=true, title="Three White Soldiers / Three Black Crows", type=bool)
OnThreeStarsInTheSouth = input(defval=true, title="Three Stars in the South", type=bool)
OnStickSandwich = input(defval=true, title="Stick Sandwich", type=bool)
OnMeetingLine = input(defval=true, title="Meeting Line", type=bool)
OnKicking = input(defval=true, title="Kicking", type=bool)
OnLadderBottom = input(defval=true, title="Ladder Bottom", type=bool)
//--- Risk Management Input ---
inpsl = input(defval = 70, title="Stop Loss", minval = 0)
inptp = input(defval = 1000, title="Take Profit", minval = 0)
inptrail = input(defval = 30, title="Trailing Stop", minval = 0)
// If the zero value is set for stop loss, take profit or trailing stop, then the function is disabled
sl = inpsl >= 1 ? inpsl : na
tp = inptp >= 1 ? inptp : na
trail = inptrail >= 1 ? inptrail : na
//--- Session Input ---
sess = input(defval = "0000-0000", title="Trading session")
t = time(timeframe.period, sess)
session_open = true
// --- Candlestick Patterns ---
//Engulfing
bullish_engulfing = high[0]>high[1] and low[0]<low[1] and open[0]<open[1] and close[0]>close[1] and close[0]>open[0] and close[1]<close[2] and close[0]>open[1] ? OnEngulfing : na
bearish_engulfing = high[0]>high[1] and low[0]<low[1] and open[0]>open[1] and close[0]<close[1] and close[0]<open[0] and close[1]>close[2] and close[0]<open[1] ? OnEngulfing : na
//Harami
bullish_harami = open[1]>close[1] and close[1]<close[2] and open[0]>close[1] and open[0]<open[1] and close[0]>close[1] and close[0]<open[1] and high[0]<high[1] and low[0]>low[1] and close[0]>=open[0] ? OnHarami : na
bearish_harami = open[1]<close[1] and close[1]>close[2] and open[0]<close[1] and open[0]>open[1] and close[0]<close[1] and close[0]>open[1] and high[0]<high[1] and low[0]>low[1] and close[0]<=open[0] ? OnHarami : na
//Piercing Line/Dark Cloud Cover
piercing_line = close[2]>close[1] and open[0]<low[1] and close[0]>avg(open[1],close[1]) and close[0]<open[1] ? OnPiercingLine : na
dark_cloud_cover = close[2]<close[1] and open[0]>high[1] and close[0]<avg(open[1],close[1]) and close[0]>open[1] ? OnPiercingLine : na
//Morning Star/Evening Star
morning_star = close[3]>close[2] and close[2]<open[2] and open[1]<close[2] and close[1]<close[2] and open[0]>open[1] and open[0]>close[1] and close[0]>close[2] and open[2]-close[2]>close[0]-open[0] ? OnMorningStar : na
evening_star = close[3]<close[2] and close[2]>open[2] and open[1]>close[2] and close[1]>close[2] and open[0]<open[1] and open[0]<close[1] and close[0]<close[2] and close[2]-open[2]>open[0]-close[0] ? OnMorningStar : na
//Belt Hold
bullish_belt_hold = close[1]<open[1] and low[1]>open[0] and close[1]>open[0] and open[0]==low[0] and close[0]>avg(close[0],open[0]) ? OnBeltHold :na
bearish_belt_hold = close[1]>open[1] and high[1]<open[0] and close[1]<open[0] and open[0]==high[0] and close[0]<avg(close[0],open[0]) ? OnBeltHold :na
//Three White Soldiers/Three Black Crows
three_white_soldiers = close[3]<open[3] and open[2]<close[3] and close[2]>avg(close[2],open[2]) and open[1]>open[2] and open[1]<close[2] and close[1]>avg(close[1],open[1]) and open[0]>open[1] and open[0]<close[1] and close[0]>avg(close[0],open[0]) and high[1]>high[2] and high[0]>high[1] ? OnThreeWhiteSoldiers : na
three_black_crows = close[3]>open[3] and open[2]>close[3] and close[2]<avg(close[2],open[2]) and open[1]<open[2] and open[1]>close[2] and close[1]<avg(close[1],open[1]) and open[0]<open[1] and open[0]>close[1] and close[0]<avg(close[0],open[0]) and low[1]<low[2] and low[0]<low[1] ? OnThreeWhiteSoldiers : na
//Three Stars in the South
three_stars_in_the_south = open[3]>close[3] and open[2]>close[2] and open[2]==high[2] and open[1]>close[1] and open[1]<open[2] and open[1]>close[2] and low[1]>low[2] and open[1]==high[1] and open[0]>close[0] and open[0]<open[1] and open[0]>close[1] and open[0]==high[0] and close[0]==low[0] and close[0]>=low[1] ? OnThreeStarsInTheSouth : na
//Stick Sandwich
stick_sandwich = open[2]>close[2] and open[1]>close[2] and open[1]<close[1] and open[0]>close[1] and open[0]>close[0] and close[0]==close[2] ? OnStickSandwich : na
//Meeting Line
bullish_ml = open[2]>close[2] and open[1]>close[1] and close[1]==close[0] and open[0]<close[0] and open[1]>=high[0] ? OnMeetingLine : na
bearish_ml = open[2]<close[2] and open[1]<close[1] and close[1]==close[0] and open[0]>close[0] and open[1]<=low[0] ? OnMeetingLine : na
//Kicking
bullish_kicking = open[1]>close[1] and open[1]==high[1] and close[1]==low[1] and open[0]>open[1] and open[0]==low[0] and close[0]==high[0] and close[0]-open[0]>open[1]-close[1] ? OnKicking : na
bearish_kicking = open[1]<close[1] and open[1]==low[1] and close[1]==high[1] and open[0]<open[1] and open[0]==high[0] and close[0]==low[0] and open[0]-close[0]>close[1]-open[1] ? OnKicking : na
//Ladder Bottom
ladder_bottom = open[4]>close[4] and open[3]>close[3] and open[3]<open[4] and open[2]>close[2] and open[2]<open[3] and open[1]>close[1] and open[1]<open[2] and open[0]<close[0] and open[0]>open[1] and low[4]>low[3] and low[3]>low[2] and low[2]>low[1] ? OnLadderBottom : na
// ---Plotting ---
plotshape(bullish_engulfing, text='Engulfing', style=shape.triangleup, color=#1FADA2, editable=true, title="Bullish Engulfing Text")
plotshape(bearish_engulfing,text='Engulfing', style=shape.triangledown, color=#F35A54, editable=true, title="Bearish Engulfing Text")
plotshape(bullish_harami,text='Harami', style=shape.triangleup, color=#1FADA2, editable=true, title="Bullish Harami Text")
plotshape(bearish_harami,text='Harami', style=shape.triangledown, color=#F35A54, editable=true, title="BEarish Harami Text")
plotshape(piercing_line,text='Piercing Line', style=shape.triangleup, color=#1FADA2, editable=false)
plotshape(dark_cloud_cover,text='Dark Cloud Cover', style=shape.triangledown, color=#F35A54, editable=false)
plotshape(morning_star,text='Morning Star', style=shape.triangleup, color=#1FADA2, editable=false)
plotshape(evening_star,text='Evening Star', style=shape.triangledown, color=#F35A54, editable=false)
plotshape(bullish_belt_hold,text='Belt Hold', style=shape.triangleup, color=#1FADA2, editable=false)
plotshape(bearish_belt_hold,text='Belt Hold', style=shape.triangledown, color=#F35A54, editable=false)
plotshape(three_white_soldiers,text='Three White Soldiers', style=shape.triangleup, color=#1FADA2, editable=false)
plotshape(three_black_crows,text='Three Black Crows', style=shape.triangledown, color=#F35A54, editable=false)
plotshape(three_stars_in_the_south,text='3 Stars South', style=shape.triangleup, color=#1FADA2, editable=false)
plotshape(stick_sandwich,text='Stick Sandwich', style=shape.triangleup, color=#1FADA2, editable=false)
plotshape(bullish_ml,text='Meeting Line', style=shape.triangleup, color=#1FADA2, editable=false)
plotshape(bearish_ml,text='Meeting Line', style=shape.triangledown, color=#F35A54, editable=false)
plotshape(bullish_kicking,text='Kicking', style=shape.triangleup, color=#1FADA2, editable=false)
plotshape(bearish_kicking,text='Kicking', style=shape.triangledown, color=#F35A54, editable=false)
plotshape(ladder_bottom,text='Ladder Bottom', style=shape.triangleup, color=#1FADA2, editable=false)
// --- STRATEGY ---
SignalUp = bullish_engulfing or bullish_harami or piercing_line or morning_star or bullish_belt_hold or three_white_soldiers or three_stars_in_the_south or stick_sandwich or bullish_ml or bullish_kicking or ladder_bottom
SignalDown = bearish_engulfing or bearish_harami or dark_cloud_cover or evening_star or bearish_belt_hold or three_black_crows or bearish_ml or bearish_kicking
strategy.entry("long", true, when = SignalUp and session_open)
strategy.entry("short", false, when = SignalDown and session_open)
strategy.close("long", when = not session_open)
strategy.close("short", when = not session_open)
strategy.exit("Risk Exit long", from_entry = "long", profit = tp, trail_points = trail, loss = sl)
strategy.exit("Risk Exit short", from_entry = "short", profit = tp, trail_points = trail, loss = sl )
